DCG Refinery Gas Standard #2, CGA 170, mole, 4.9 L @ 60 psig

Compound, % of each compound*
Hydrogen, 12.500 %
Argon, 1.000 %
Nitrogen, 37.200 %
Carbon monoxide, 1.000 %
Carbon dioxide, 3.000 %
Methane, 5.000 %
Ethane, 4.000 %
Ethylene, 2.000 %
Acetylene, 1.000 %
Propane, 6.000 %
Propylene, 3.000 %
Propadiene, 1.000 %
Cyclopropane, 0.040 %
Isobutane, 5.000 %
N-Butane, 4.000 %
Isobutylene, 1.000 %
1,3 Butadiene, 3.000 %
cis-2-Butene, 2.000 %
trans-2-Butene, 3.000 %
1-Butene, 2.000 %
2-Methyl-2-butene, 0.200 %
Isopentane, 1.000 %
N-Pentane, 1.000 %
cis-2-Pentene, 0.400 %
trans-2-Pentene, 0.160 %
Pentene-1, 0.400 %
N-Hexane, 0.100 %

*Precise concentrations are provided on the data sheet included with each cylinder and may vary slightly from those listed here.

Concentration: mole
Volume: 4.9 L @ 60 psig (414 kPa)

DCG Partnership Cylinders:
Size: 7.6 x 24 cm
Connection: CGA-170/110
U.S. DOT Specs: DOT-4B-240ET

Features & Benefits

Available in three mixes with varying C5 unsaturates or extended C6+ components.

Note: Actual cylinder pressure may vary due to loss from quality testing procedure.

To view compatible regulators, see Often Purchased with below.

Product Specifications
